HIGH SPEED OVER MOLDED UNIVERSAL MICRO USB 2.0 CHARGER CABLE

HIGH SPEED OVER MOLDED UNIVERSAL MICRO USB 2.0 CHARGER CABLE
Features:
1.high speed to 480mbps
2.micro B male to USB A male
3.over molded
4.cable spec:28AWG*1P+28AWG*2C+AL+Braid
5.CE ROHS compliance
Electrical:
100% open & short test | ||
Voltage : 300V DC, 5MΩ/10ms | ||
Insulation Resistance: 10M OHM /300V Min. | ||
Contact Resistance: 0.01 OHM Max. | ||
Shield up to 65% braid. | ||
Working Temperature: -25 ° ~ +80 ° |
Mechanical:
Over mold: PVC 70Pa UL94V-0 |
Pre mold: PE Low Density |
Contact: Copper Alloy. |
Insertion Force: 35 N Max. |
Withdraw Force: 10 N Min |
Production process:
Shipping Information:
We guarantee to ship out within five to seven days after the confirmation of your payment.(Except Holiday).
In order to ensure you receive your order tax free upon import, we will declare small sample order as a 'GIFT' with a lower value.
This lower price does not reflect the total price you paid or the market value of the product. And it may not apply to countries with different tariff rules. Any import charges or fees are the buyer's responsibility.
Delivery time is approximately15 to 20 working days (excluding Saturday & Sunday, Public Holiday) to most destinations.
We are not responsible for any accidents, delays or other issue aroused by the shipping service.For item's safety, insurance is highly recommended.
Please confirm and make sure the shipping address is correct. We are not responsible for any wrong or undeliverable addresses.
